FEATURE:
► As per DIN 5262 and ISO 2380
SPECS:
► Blade: S2 steel , sadin + black tip (manganese phosphate)
|
Item No. |
Tip Size |
Shank
Length |
Shank
Dia |
Handle Size |
SAE |
Weight |
|
CS00583 |
0.5 x 3.0 mm |
75 mm |
3.2 mm |
78 x 25 mm |
1/8" x 3" |
25 g |
|
CS00583-01 |
0.5 x 3.0 mm |
80 mm |
3.2 mm |
78 x 25 mm |
1/8" x 3" |
25 g |
|
CS00583-02 |
0.5 x 3.0 mm |
100 mm |
3.2 mm |
78 x 25 mm |
1/8" x 4" |
28 g |
|
CS00583-03 |
0.8 x 4.0 mm |
75 mm |
4.0 mm |
78 x 25 mm |
5/32" x 3" |
56 g |
|
CS00583-04 |
0.8 x 4.0 mm |
100 mm |
4.0 mm |
100 x 31 mm |
5/32" x 4" |
61 g |
|
CS00583-05 |
1.0 x 5.5 mm |
75 mm |
5.0 mm |
100 x 31 mm |
3/16" x 3" |
56 g |
|
CS00583-06 |
1.0 x 5.5 mm |
100 mm |
5.0 mm |
100 x 31 mm |
3/16" x 4" |
61 g |
|
CS00583-07 |
1.0 x 5.5 mm |
125 mm |
5.0 mm |
100 x 31 mm |
3/16" x 5" |
63 g |
|
CS00583-08 |
1.0 x 5.5 mm |
150 mm |
5.0 mm |
100 x 31 mm |
3/16" x 6" |
72 g |
|
CS00583-09 |
1.2 x 6.5 mm |
100 mm |
6.0 mm |
113 x 35 mm |
1/4" x 4" |
88 g |
|
CS00583-10 |
1.2 x 6.5 mm |
125 mm |
6.0 mm |
113 x 35 mm |
1/4" x 5" |
94 g |
|
CS00583-11 |
1.2 x 6.5 mm |
150 mm |
6.0 mm |
113 x 35 mm |
1/4" x 6" |
98 g |
|
CS00583-12 |
1.2 x 6.5 mm |
200 mm |
6.0 mm |
113 x 35 mm |
1/4" x 8" |
117 g |
|
CS00583-13 |
1.2 x 6.5 mm |
300 mm |
6.0 mm |
113 x 35 mm |
1/4" x 12" |
137 g |
|
CS00583-14 |
1.2 x 8.0 mm |
150 mm |
8.0 mm |
121 x 38 mm |
5/16" x 6" |
148 g |
|
CS00583-15 |
1.2 x 8.0 mm |
175 mm |
8.0 mm |
121 x 38 mm |
5/16" x 7" |
160 g |
|
CS00583-16 |
1.2 x 8.0 mm |
200 mm |
8.0 mm |
121 x 38 mm |
5/16" x 8" |
180 g |
|
CS00583-17 |
1.0 x 5.5 mm |
38 mm |
5.0 mm |
67 x 33 mm |
3/16" x 1 1/2" |
46 g |
|
CS00583-18 |
1.2 x 6.5 mm |
38 mm |
6.0 mm |
67 x 33 mm |
1/4" x 1 1/2" |
48 g |
PACKING:
► Plastic hanger
|
