FEATURE:
► As per DIN 5262 and ISO 2380
► Hexagon blade with hexagon bolster
SPECS:
► Blade: S2 steel , sadin + black tip (manganese phosphate)
|
Item No. |
Tip Size |
Shank
Length |
SW |
Hexagon
Bolster |
Handle Size |
SAE |
Weight |
|
CS00582 |
1.0 x 5.5 mm |
75 mm |
10 |
6.3 mm |
100 x 31 mm |
3/16" x 3" |
98 g |
|
CS00582-01 |
1.0 x 5.5 mm |
100 mm |
10 |
6.3 mm |
100 x 31 mm |
3/16" x 4" |
100 g |
|
CS00582-02 |
1.2 x 6.5 mm |
100 mm |
10 |
6.3 mm |
113 x 35 mm |
1/4" x 4" |
120 g |
|
CS00582-03 |
1.2 x 6.5 mm |
150 mm |
10 |
6.3 mm |
113 x 35 mm |
1/4" x 5" |
150 g |
|
CS00582-04 |
1.2 x 8.0 mm |
150 mm |
12 |
8.0 mm |
121 x 38 mm |
5/16" x 6" |
200 g |
|
CS00582-05 |
1.2 x 8.0 mm |
200 mm |
12 |
8.0 mm |
121 x 35 mm |
51/6" x 8" |
230 g |
PACKING:
► Plastic hanger
|
