SPECS :
► Special designed clamping jaws hold the wire
securely during the stripping process
► Powder metal jaws, hardness HV 450 to 650°
(HRC 52 to 57°)
► With additional swivel knob, adjust to strip wire
maximum 8AWG (8mm²), minimum 30AWG
(0.05mm²)
► Romax cable 14/2; 12/2 or NM-B cable 10-14AWG.
► Body constructed by metal with heat treatment
► Adjustable stop controls the length of wire be stripped
► Crimp insulated, non-insulated, and auto ignition
terminals
► With extra cutting function for regular solid or
stranded cable
► Weight: 337g
► Length: 205mm
FEATURES :
► Standard stripping and cutting gauge 10-26AWG
(0.13 to 6mm²)
► Swivel knob micro-adjusts for thinner wire to 30AWG
(0.05mm²) or thicker wire to 8 AWG (8mm²)
► Crimp non-insulated terminals 10-22AWG
(1.5 to 6.0 mm²)
► Crimp insulated terminals 10-22AWG
(1.5 to 6.0 mm²)
► Crimp auto ignition terminals 7 to 8mm
|
