SPECS:
|
Item. NO |
JS01217 |
JS01217-01 |
|
Air Inlet |
PT/NPT |
1/4" |
|
Hose Inlet |
Inch |
3/8" |
|
Blows Per Minute |
BPM |
300 |
|
Air Comsumption |
CFM (LPM) |
7.4 (210) |
|
Piston Diameter |
mm |
Ø20 x 48 |
|
Piston Stroke |
mm (inch) |
57.5 (2.3) |
|
Chisel Shank |
mm (inch) |
12.7 (0.5)
Round
|
11.8 (0.464)
Hex
|
|
Overall Length |
mm (inch) |
257 (10.1) |
|
Net Weight |
kg (lb) |
1.6 (3.5) |
|
Air Pressure |
PSI (Bar) |
≦90 (6.2) |
|
Soud Pressure Level |
dBA |
103 |
|
Soud Power Level |
dBA |
114 |
|
Vibration Level |
M/ Sec2 |
24.01 |
FUNCTION:
► Choice of bushing: 0.464" Hex, prevents chisel rotation;
0.5" Round, chisel rotates freely.
► Unique ring valve as standard for harder blow in tough
applications.
► Rugged construction, heat treated cylinder and forged
handle.
► Pistol grip handle with self closing outside trigger.
► Chrome plated cylinder for extra durability.
► Teasing throttle for precise control.
|
