Item No. |
Size |
Description |
|
Item No. |
Size |
Description |
|
Item No. |
Size |
Description |
|
Item No. |
Size |
Description |
|
BS00287 |
Suitable for insulated terminal
AWG 22-18 / 16-14 / 12-10
DIN 0.5-1.0 / 1.5-2.5 / 4-6 mm²
|
 |
BS00287-12 |
Suitable for open barrel terminal
AWG 26-24 / 24-22 / 22-18
DIN 0.1-0.25 / 0.25-0.5 / 0.5-1.0 mm²
|
 |
BS00287-24 |
Suitable for spark plug connector
AWG 17
1 mm²
|
 |
BS00287-36 |
Suitable for deutsch contact
AWG 14 / 12
|
 |
|
BS00287-01 |
Suitable for heat shrink butt connector
AWG 22-18 / 16-14 / 12-10 / 8
DIN 0.5-1.0 / 1.5-2.5 / 4-6 / 10 mm²
|
 |
BS00287-13 |
Suitable for cord end terminal
AWG 20 / 18 / 17 / 16 / 14 / 12
DIN 0.5 / 0.75 / 1.0 / 1.5 / 2.5 / 4.0 mm²
|
 |
BS00287-25 |
Suitable for AMP superseal 1.5 type terminal
AWG 22-20 / 16
DIN 0.35-0.5 / 1.5 mm²
|
 |
BS00287-37 |
Suitable for deutsch contact
AWG 10 / 12
6 / 5 mm²
|
 |
|
BS00287-02 |
Suitable for fully insulated quick
disconnect
AWG 22-18 / 16-14 / 12-10
DIN 0.5-1.0 / 1.5-2.5 / 4-6 mm²
|
 |
BS00287-14 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.255"" / .213"" / .100"" / .068"" / .324""]
[6.48 / 5.41 / 2.54 / 1.72 / 8.23mm]"
Specification: RG 58, 59, 62, 6
|
 |
BS00287-26 |
Suitable for AMP superseal 1.5 type terminal
AWG 18 / 17
DIN 0.75 / 1.0 mm²
|
 |
BS00287-38 |
Suitable for deutsch contact
AWG 18 / 16 / 14
|
 |
|
BS00287-03 |
Suitable for miniature insulated terminal
AWG 26-22 / 24-18 / 22-16
DIN 0.1-0.5 / 0.25-1.0 / 0.5-1.56 mm²
|
 |
BS00287-15 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.255"" / .187"" / .068"" / .213""]
[6.48 / 4.75 / 1.72 / 5.41mm]"
Specification: RG 58, 59, 62, 174
|
 |
BS00287-27 |
Suitable for AMP superseal 1.5 type terminal
AWG 22-20 / 18 / 17 / 16
DIN 0.35-0.5 / 0.75 / 1.0 / 1.5 mm²
|
 |
BS00287-39 |
Suitable for deutsch contact
AWG 20 / 18 / 16
|
 |
|
BS00287-04 |
Suitable for insulated flag terminal
AWG 22-18 / 16-14
DIN 0.5-1.0 / 1.5-2.5 mm²
|
 |
BS00287-16 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.256"" / .319"" / .068"" / .213""]
[6.50 / 8.10 / 1.72 / 5.41mm]"
Specification: RG 58, 59, 62, 6
|
 |
BS00287-28 |
Suitable for delphi weather pack terminal
AWG 20-18 / 16-14 / 12
DIN 0.5-0.8 / 1.0-2.0 / 3.0 mm²
|
 |
BS00287-40 |
Suitable for deutsch contact
AWG 20 / 18 / 16
|
 |
|
BS00287-05 |
Suitable for closed end connector &
heat shrink terminal
AWG 22-16 / 16-14 / 12-10
DIN 0.5-1.5 / 1.5-2.5 / 4-6 mm²
|
 |
BS00287-17 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.043"" / .068"" / .100"" / .137"" / .213"" / .255""]
[1.09 / 1.72 / 2.54 / 3.48 / 5.41 / 6.48mm]"
Specification: RG 58, 59, 62, 174, fiber optic
|
 |
BS00287-29 |
Suitable for Delphi weather pack terminal
AWG 22 / 20-18
DIN 0.35 / 0.5-0.8 mm²
|
 |
BS00287-41 |
Suitable for deutsch contact
AWG 16 / 14 / 12
|
 |
|
BS00287-06 |
Suitable for insulated flag terminal
AWG 12-10
DIN 4-6 mm²
|
 |
BS00287-18 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.100"" / .128"" / .429""]
[2.54 / 3.25 / 10.9mm]"
Specification: RG 8, 11, 174, 179, 213
|
 |
BS00287-30 |
Suitable for delphi weather pack terminal
AWG 16-14 / 12
DIN 1.0-2.0 / 3 mm²
|
 |
BS00287-42 |
Suitable for deutsch contact
Size 20 / 16 / 12
For DTM / DT / DTP
|
 |
|
BS00287-07 |
Suitable for non-insulated terminal
AWG 20-16 / 16-14 / 12-10 / 8
DIN 0.5-1.5 / 1.5-2.5 / 4-6 / 10 mm²
|
 |
BS00287-19 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.042"" / .068"" / .078"" / .128"" / .151"" / .178""]
[1.07 / 1.72 / 1.98 / 3.25 / 3.84 / 4.52mm]"
Specification: RG 174, 179, belden 8218, fiber optic
|
 |
BS00287-31 |
Suitable for MC4 solar connector
AWG 14 / 12 / 10
DIN 2.5 / 4.0 / 6.0 mm²
|
 |
BS00287-43 |
Suitable for JPT receptacle contact
AWG 24-13
DIN 0.2-0.5 / 0.2-0.5 / 0.5-1.0 / 1.5-2.5 mm²
|
 |
|
BS00287-08 |
Suitable for non-insulated terminal
AWG 6 / 4
DIN 16 / 25 mm²
|
 |
BS00287-20 |
Suitable for RG type coaxial cable connector
Coaxial cable connectors
[.100"" / .213"" / .319"" / .360""]
[2.54 / 5.41 / 8.10 / 9.14mm]"
Specification: RG 58, 59, 6
|
 |
BS00287-32 |
Suitable for open barrel Splice
AWG 26-24 / 24-22 / 22-18 / 16-14
DIN 0.1-0.25 / 0.25-0.5 / 0.5-1.0 / 1.5-2.5 mm²
|
 |
BS00287-44 |
Suitable for JPT & MCP flat contact
AWG 20-14
DIN 0.5-1.0 / 1.5-2.5 / 0.5-1.0 / 1.5-2.5 mm²
|
 |
|
BS00287-09 |
Suitable for open barrel terminal
AWG 20-18 / 16-14 / 12-10
DIN 0.5-1.0 / 1.5-2.5 / 4-6 mm²
|
 |
BS00287-21 |
Suitable for cord end terminal
AWG 10 / 8 / 6
DIN 6 / 10 / 16 mm²
|
 |
BS00287-33 |
Suitable for MC3 solar connector
AWG 12 / 10 / 14
DIN 4.0 / 6.0 / 2.5 mm²
|
 |
BS00287-45 |
Suitable for JT & ST receptacle contact
AWG 20-13
DIN 0.5-1.0 / 1.5 / 1.0-1.5 / 2.5 mm²
|
 |
|
BS00287-10 |
Suitable for open barrel terminal
AWG 20-18 / 16-14 / 12-10
DIN 0.5-1.0 / 1.5-2.5 / 4-6 mm²
|
 |
BS00287-22 |
Suitable for cord end terminal
AWG 4 / 2
DIN 25 / 35 mm²
|
 |
BS00287-34 |
Suitable for MC4 solar connector
AWG 14 / 12 / 10
DIN 2.5 / 4.0 / 6.0 mm²
|
 |
BS00287-46 |
Suitable for SPT receptacle contact(SWS)
AWG 20-17 / 17-13 / 13-11
DIN 0.5-1.0 / 1.5-2.5 / 3.0-4.0 mm²
|
 |
|
BS00287-11 |
Suitable for open barrel terminal
AWG 20-18 / 16-14 / 12-10
DIN 0.5-1.0 / 1.5-2.5 / 4-6 mm²
|
 |
|
BS00287-23 |
Suitable for open barrel terminal & D-Sub, V.35
AWG 14 / 22 / 8-6
DIN 2.5 / 0.5 / 8-10 mm²
|
 |
|
BS00287-35 |
Suitable for tyco solar connector
AWG 15-10
DIN 1.5 / 2.5 / 4.0 / 6.0 mm²
|
 |
|
|
|
