► Rail: Medium carbon steel with nickel and chrome plating.
► Wooden handle.
► Gardened scerws for strong tightening force.
► Clamping force: 200kgf.
► The Anti-Slip system is really handy in work.
► Parallel jaw:
Material: Polyamide.
The large clamping area and parallel jaws allow the work easier
and prevent damaging your workpiece.
► Pad: Material: Steel.
► Arm: Ductile cast iron.
► Stopper: Material: Polyamide
Prevents the sliding arm moving off.
Can be taken off by hand for quickly changing the siding arm
direction to use for spreading.
Also can be a hold with the fixed arm to put on the table for
horizontal clamping.
|
item NO. |
Span × Depth |
Spreading |
Rail |
Weight |
Pressure |
Pack |
|
DS01036 |
160 × 80mm |
172~270mm |
20.0 × 5.0mm |
0.6kg |
200kg |
10pcs |
|
DS01036-01 |
300 × 80mm |
172~415mm |
0.7kg |
|
DS01036-02 |
600 × 80mm |
172~720mm |
0.9kg |
