SPECS:
► Traction power: 1045kg.f(2303lbs.f) at 6.0kg/cm²(85PSI)
► Stroke length: 16mm(0.708")
► Net weight: 1.480kgs(3.262lbs)
► Air preeure: 5.5~6.0kg/cm²(78~85PSI)
► Nose piece: 2.4(3/32"), 3.2(1/8"), 4.0(5/32") , 4.8(3/16")
► Width × height: 170mm × 265mm
► Air consumption: 1.48 liter/ cycle
► Air hose size x Intel thread: 6.5mm(1/4")I.D. × 1/4"PT(NPT)
Material |
Rivet Diameter(Ømm) |
Rivet |
Mandrel |
2.0 |
2.4(2.5) |
3.2(3.0) |
4.0 |
4.8(5.0) |
6.4 |
Aluminum |
Aluminum |
★ |
★ |
★ |
★ |
★ |
- |
Aluminum |
Steel |
★ |
★ |
★ |
★ |
★ |
- |
Steel |
Steel |
★ |
★ |
★ |
★ |
★ |
- |
Stainless |
Steel |
★ |
★ |
★ |
★ |
★ |
- |
Stainless |
Stainless |
★ |
★ |
★ |
★ |
★ |
- |
|
