SPECS:
► Traction power: 1700kg.f(3747lbs.f) at 6.0kg/cm²(85PSI)
► Stroke length: 18mm(0.70")
► Net weight: 1.750kgs(3.858lbs)
► Air pressure: 6.0~6.5kg/cm²(85~92PSI)
► Nose piece: 2.4(3/32"), 3.2(1/8"), 4.0(5/32") , 4.8(3/16"), 6.0, 6.4(1/4")
► Width × height: 170mm × 298mm
► Air consumption: 2.908 liter/ cycle
► Air hose size x Intel thread: 6.5mm(1/4")I.D. × 1/4"PT(NPT)
|
Material |
Rivet Diameter(Ømm) |
|
Rivet |
Mandrel |
2.0 |
2.4(2.5) |
3.2(3.0) |
4.0 |
4.8(5.0) |
6.4 |
|
Aluminum |
Aluminum |
★ |
★ |
★ |
★ |
★ |
★ |
|
Aluminum |
Steel |
★ |
★ |
★ |
★ |
★ |
★ |
|
Steel |
Steel |
★ |
★ |
★ |
★ |
★ |
★ |
|
Stainless |
Steel |
★ |
★ |
★ |
★ |
★ |
★ |
|
Stainless |
Stainless |
★ |
★ |
★ |
★ |
★ |
★ |
|
