SPECS :
|
Cutting capacity 90° |
● 2"(50 mm)
○ 4"(100 mm)
□ 3.2" x 3.2"(82 x 82 mm)
▭ 4.3" x 2.8"(110 x 70 mm)
|
|
Cutting capacity 45° |
● 2"(50 mm)
○ 4"(100 mm)
□ 3.2" x 3.2"(82 x 82 mm)
▭ 3.3" x 2.8"(85 x 70 mm)
|
|
Main Motor |
2 HP / 3 PH / 2P / 4P |
|
Spindle speed |
50 Hz 44 / 88 rpm
60 Hz 52 / 104 rpm
|
|
Saw blade |
HSS 0.08" x 1.25"(2 x 32 mm)
Ø12"(315 mm)
|
|
Maximum vise opening |
Ø4.7"(120 mm) |
|
Cooling pump |
1/8 HP |
|
Coolant tank |
5 L |
|
Machine weight(kgs) |
175(with stand) |
|
Machine dimensions
(L x W x H)with stand
|
40" x 39" x 72"
(1020 x 990 x 1830 mm)
|
|
Stand dimensions
(L x W x H)
|
23.6" x 20" x 28.5"
(600 x 510 x 725 mm)
|
Features :
► Stand-alone coolant system with high volume tank.
► Specially designed water way for better
cooling effect.
► Adjustable setting with scales for better cutting
length measurement.
► Heavy duty design for easy work-piece loading.
► Shock-proof design for control panel.
► Miter design for cutting angle adjustment 45 on the
right and left respectively
|
