Max. drilling capacity

32 mm

 Chuck

16 mm (19mm for option)

 Spindle taper

MT3 (MT4 for option)

 Spindle taper

116 mm

 Swing

558 mm

 Number of speed

12

 Rotate speed (R.P.M.) 50Hz

150-3400

 Rotate speed (R.P.M.) 60Hz

180-4200

 Max. Distance from spindle to table

680 mm

 Max. Distance from spindle to base

1220 mm

 Diameter of column (mm)

92 mm

 Size of table (mm)

419 x 475 mm

 Size of base (mm)

500 x 570 mm

 Overall height (mm)

1760 mm

 Input power

1HP (1.1/2HP for option)

 N.W. / G.W. (kg)

160 / 169 kg

 Cuft

7.16'
