Item No. |
LS00019 |
LS00019-01 |
|
Motor |
2 HP / 60HZ ,
1.5 KW / 50 HZ |
3 HP / 60HZ ,
2.25 KW / 50 HZ |
Air suction
w/o bag |
1600 CFM ,
2100 m³/h |
2200 CFM ,
2860 m³/h |
|
Max. static pressure |
9.2 InH₂O ,
234 mmAq |
11.2 InH₂O ,
285 mmAq |
|
Inlet diamete |
8" x 4" x 2 |
8" x 4" x 3 |
|
Drum capacity |
28 gallon |
60 gallon |
|
Noise rate (@3M) |
76 dB |
78 dB |
|
Filter surface |
3.7 M² |
6.5 M² |
Overall size
(L x W x H) |
1000 x 670 x 1700mm |
1200 x 670 x 2200mm |
Packing size
(L x W x H) |
1200 x 1170 x 710mm |
Machine:
1250 x 720 x 1185mm
Canister:
1580 x 490 x 510mm
|
|
N.W./ G.W./ CUFT |
131kgs/ 149kgs/ 35.2' |
Machine:
139kgs/ 158kgs/ 37.7'
Canister:
40.5 kgs/ 45.5 kgs/ 15.2'
|
FEATURES:
► Canister filters always resist more hazardous fine dust before
it can become airborne or enter your lungs.
► Auto cleaning system can easily help to clean the canister
filter with only one tough switch.
► Cartridge filter is made of spun-bond polyester that filters
99.9% of particles from 0.2 to 2 microns in size.
PACKING:
► Pallet
