SPECS :
|
Drilling capacity |
Steel : MT3 1-1/4"(32 mm)
MT4 1-1/2"(40 mm)
|
|
Tapping capacity |
3/4"(19 mm)
|
|
Swing |
18.3"(465 mm) |
|
Spindle taper |
MT3#, MT4# |
|
Spindle travel |
6"(150 mm) |
|
Quill diameter |
3"(75 mm) |
|
Column diameter |
4-1/2"(115 mm) |
|
Spindle nose to table |
18"(460 mm) |
|
X axis travel |
16.9"(430 mm) |
|
Y axis travel |
9"(230 mm) |
|
Table size(L x W) |
28.7" x 8.3"(730 x 210 mm) |
|
Table slot |
5/8"(16 mm) |
|
Base size(L x W) |
26.3" x 15.7"(670 x 400 mm) |
|
Spindle speed |
High : 245~2000 rpm
Low : 65~540 rpm
|
|
Motor |
2 HP / 3 HP |
|
Coolant motor |
1/8 HP / 3 PH |
|
Machine size(L x W x H) |
41.3" x 43.3" x 54"
(1050 x 1100 x 1370 mm)
|
|
Stand size(L x W x H) |
29.5" x 22" x 31"
(750 x 560 x 790 mm)
|
|
Net weight |
287 kgs |
|
Measurement |
27.4 CU.FT. |
Features :
► Forward and reverse tapping system.
► Digital tachometer display.
|
