SPECS :
|
Motor power |
1-1/2 HP/ 1.12 KW
110 V / 220 V
|
|
Fence |
800 mm(31.5") |
|
Max. boring depth |
64 mm(2.5") |
|
Number of spindle heads |
13(Left 6 + Right 7) |
|
Table size |
800 x 400 mm(31.5" x 15.75") |
|
Spindle center |
32 mm |
|
Shank diameter |
Ø 10 mm |
|
Spindle speed |
2800 rpm / 3450 rpm |
|
Max depth(bit to fence) |
102 mm(4") |
|
Table height from floor |
848 mm(33.38") |
|
Machine dimension(D x W x H) |
130 x 190 x 174.7 cm |
|
Net / Gross weight |
82 / 97 kgs
|
Features :
► Fully adjustable fence system with easy to read
scales in both inches and metric for quick setup
and accurate boring.
► Manually quick clamp devices.
► Heavy-duty cast iron construction machined
with precision.
► Indexing pins to remain correct spindle alignment for
resuming line boring operations in long workpiece.
► Work stops on either end of the fence allow operator
to line up work from the left to right for performing
parallel boring patterns.
► Adjustable depth stop control.
|
