SPECS :
|
Chisel capacity |
6-16 mm(1/4"~5/8") |
|
Max chisel stroke |
153 mm(6") |
|
Distance(from fence to center chisel) |
76 mm(3") |
|
Distance(from center chisel to table) |
152 mm(6") |
|
Chuck capacity |
13 mm(1/2") |
|
Speed of spindle |
50 Hz / 2850 rpm
60 Hz / 1720 rpm
|
|
Size of table |
185 x 290 mm(7.3" x 11.42") |
|
Size of base |
196 x 287 mm
(7.7" x 11.3")
|
|
Motor |
0.37 kw(1/2HP) |
|
Overall height |
680 mm(26.8") |
|
Net / Gross weight |
66 lbs(30 kgs) /
70.5 lbs(32 kgs)
|
Features :
► Cast-iron construction.
► Smooth rack and pinion action lowers the entire
head feed mortiser accurately into work piece.
► Head performs 180° overhead rotation.
|
