SPECS:
► Motor / with brake: 3HP * 1PH * 2P (2850RPM)
4HP * 3PH * 2P (2850RPM)
► Arbor: 1", 30mm bush
► Blade: 14", 16"
► Max. depth cut at 90°: 5" (127mm) for 16" blade
► Max. bevel cut depth at 45°:
2.5"(65mm) for 16" blade
► Crosscut capacity: 24" (609mm) max. at 1" cut depth
► Rip cut capacity: 38.2" (970mm)
► Dado capacity: 1-1/4" (31mm)
► Bevel positive stops: 0, 45, 90 degree
► Miter positive stops: 90°, 45° left and right.
► Wood table: 1010 x 1220mm
|
