SPECS:
|
Motor: |
3/4 HP/60HZ / 0.56KW/50HZ |
|
Air suction capacity w/canister: |
750 CFM / 1000 M3/H |
|
Static pressure: |
6.5 INH2O / 165M MAG |
|
Inlet diameter: |
4" |
|
Bag capacity: |
27 gallon |
|
Overall dimension: |
730 x 390 x 670mm |
|
Packing size: |
(Machinery) 725 x 440 x 470mm
(Canister filter) 440 x 440 x 720mm
|
|
N.W. / G.W. / CUFT.: |
(machinery) 25kgs / 28kgs / 5.3'
(canister filter) 7kgs / 9kgs / 5'
|
FEATURES:
► With the canister filter, the operator just need simple to turn the handle
120 degree for cleaning the dust.
► The handle can rotate a cleaning flapper inside and shake the dust
from the filter letting, and the fine dust will fall down directly into the
collection bag.
► The filter material in cartridge filter is made of spun-bond polyester,
capable of filtering dust particles down to 1 micron
PACKING:
► Carton box
|
