SPECS:
|
Item NO. |
LS00139 |
|
Motor |
3/4(1HP) / 60Hz |
0.56KW / 50Hz |
|
Air suction capacity
w/canister
|
790 CFM |
1050 m3/h |
|
Static pressure |
5.4 InH2O |
137 mmAg |
|
Inlet diameter |
4" x 1 |
102 mm x 1 |
|
Canister filter diameter |
14-1/2" |
370 mm |
|
Canister filter height |
23-5/8" |
600 mm |
|
Sound rating
(noise)
|
55-65dB |
|
Overall dimension
(L x W xH)
|
720 x 380 x 1460 mm |
|
Packing size
(L x W xH)
|
Machinery: 675 x 410 x 455 mm
Canister: 440 x 440 x 720 mm
|
|
N.W. / G.W. / CUFT. |
Machinery: 22kgs / 25kgs / 4.4'
Canister: 7kgs / 9kgs / 4.8'
|
FEATURES:
► With the canister filter, the operator just need simple to
turn the handle 360 degree for cleaning the dust.
► The handle can rotate a cleaning flapper inside and shake
the dust from the filter letting, and the fine dust will fall
down directly into the collection bag.
► The pleated filter contain more than 5 times the filtering
surface area comparing with standard filter bags.
► The filter material in cartridge filter is made of spun-bond
polyester, capable of filtering dust particles down to 1
micron.
|
