SPECS:
|
Motor: |
1.1/2HP / 60HZ / 1125 WAT / 50HZ |
|
Motor speed: |
1720 / 1462 |
|
Table size: |
20" x 12" / 508 x 305mm |
|
Table tilting: |
Up 0-15, down 0-45 degree |
|
Overall dimension: |
520 x 680 x 135 mm |
|
Packing size: |
750 x 20 x 1300 mm |
|
N.W. / G.W. / CUFT.: |
86kgs / 96kgs / 15' |
FEATURES:
► Powerful 1.1/2HP (1125 watt) motor drive and cast
iron motor housing for efficient heat dissipation.
► With a brake which able to stop the disc running
with-in 6 sec.
► Equipped with diameter 2.1/2" (63mm) dust chute for
easy hose connection.
► Cast iron table and disc good for heavy-duty
woodworking and table up t0 45 degree.
► Strong close type stand with optional built in
3/4 hp dust collector with mite gage.
► Optional 2HP (1500 WATT) motor
PACKING:
► Carton box
|
