SPECS:
|
Motor: |
2HP / 220V / 1-Phase or 3-Phase (optional) |
|
AMPS: |
12A / 9A |
|
Motor speed: |
1720 RPMM / 60 HZ |
|
Table: |
27.5" 2 x 10.5" deep cast iron table |
|
Table tilting: |
table adjustable up 15 degree and
down 45 degree W/warm gear
|
|
Dust port: |
2.1/2" |
|
Overall dimension
(W x D x H):
|
27.1/2" x 25" x 48" |
|
Packing size: |
660 x 1300 x 660 mm |
|
N.W. / G.W. / CUFT.: |
182kgs / 200kgs / 36' |
FEATURES:
► Heavy duty cast iron construction for plenty of mass
operation.
► Adjustable height work table with rack and pinion
control.
► Reverse rotation allows for use whole table.
► 27.5" W x 10.5" deep cast iron large precision table.
► Built-in manual brake for quick stop.
► Table able to gear down for easy sanding paper change.
► Optional 3HP motor.
PACKING:
► Carton box
|
