SPECS:
|
Max. Sanding width |
18" / 457.2 mm |
|
Max. Thickness of workpiece |
5" / 127 mm |
|
Min. Thickness of workpiece |
1/4" / 6.35 mm |
|
Drum speed |
50 HZ 1420 RPM /
60 HZ-1720 RPM
|
|
Freed speed |
6-30 FPM |
|
Drum diameter |
3.2" / 82 mm |
|
Drum length |
16" / 407 mm |
|
Drum drive motor |
3 HP |
|
Feed drive motor |
1/4 HP |
|
Dust hood outlet diameter |
Ø4" / 100 mm |
|
N.W. / G.W.: |
215kgs / 285kgs |
|
Packing dimensions |
103 x 86 x 174 cm
|
* All specifications, dimensions and design characteristics
shown are subject to change without prior notice.
FEATURES:
► Open end sander provides up to 36" sanding
capacity.
► Rugged rubber covered drum support frame.
► Configuration of two sanding drums provides
highly efficient sanding performance.
► A depth scale in both inches and metric graduation
is prouided on the drum support frame for
indicating the thickness adjustment amount.
► Table, belt, tracking is easy to adjust.
► Easy operation for sanding belt replacement.
► The sanding drum is driven by 3HP motor.
► Machine drum will be swinging left and right to
avoid wood chips attached to the sanding belt.
► Extension table is adjustable according to operator's
requirement.
PACKING:
► Plywood case
|
