SPECS:
|
Speed |
4000 RPM |
|
Diameter of arbor |
5/8" (16mm) |
|
Diameter of sawblade |
10" (254mm) |
|
Max. Depth of cut |
3.1/4" (82mm) |
|
Max. Depth of cut at 45° |
2.1/8" (54mm) |
|
Distance in front of blade |
12" (300mm) |
|
Table |
686(L) x 512(W) mm |
|
Extension wing |
686(L) x 245(W) mm |
|
Motor |
1.1/2 HP |
|
N.W. / G.W.: |
105kgs / 110kgs |
|
Packing dimensions |
27.7/8" x 2.5/8" x 18.1/2" |
* All specifications, dimensions and design
characteristics shown are subject to change
without prior notice.
FEATURES:
► Equipped with a 3hp motor for heavy duty cutting.
► Main and scoring saw blades ensure tear-free
cutting.
► Ruggedly constructed saw carriage provides
maximum cutting stability.
► Heavy, precision-machined trunnion ensures
accurate saw tilting.
► Fence locks securely and precisely parallel to
the saw blade.
► Durable saw blade guard for operator safety.
► Fitted with precision fence for high accuracy cuts.
► The blade guard can be dismount easily to facilitate
maintenance purpose.
► The riving knife can perform vertical adjustment with
the mein saw blade.
PACKING:
► Carton box + plywood case
|
