SPECS:
|
Drum length |
13" |
|
Max. thickness of work piece |
4" |
|
Min. Thickness of work piece |
1/4" |
|
Sanding drum speed |
860 RPM |
|
Conveyor belt speed |
3-20 FPM |
|
Sanding drum motor |
1.5HP |
|
Feed drive motor |
1/15HP (DC) |
|
Sanding drum diameter |
5" |
|
N.W. / G.W.: |
114.5kgs / 153kgs |
|
Machine dimensions (include stand) |
35" x 25" x 48" |
* All specifications, dimensions and design characteristics
shown are subject to change without prior notice.
FEATURES:
► 1.5HP drive for sanding drum.
► An economical sander provides 13" sanding width
capacity.
► Variable feed speed 6-28 FPM.
► High quality conveyor belt for long service life.
► Dynamically balanced sanding drum ensure smooth
running.
► One sanding drum configuration provides high
efficiency sanding performance.
► Conveyor belt tracking is convenient to adjust.
► Convenient replacement of sanding belt
PACKING:
► Plywood case
|
