SPECS:
|
Item No. |
LS00382 |
LS00382-01 |
|
Motor |
1/3HP |
1/2HP |
|
Table size |
31-1/2" x 21-1/4"
(800 x 540 mm)
|
37" x 25-1/2"
(940 x 640mm)
|
|
Table height |
3-1/2" (800 mm) |
|
Filter micron |
0.5 |
|
Airflow capacity |
1300 CFM |
1600 CFM |
|
Overall size
(L x W x H)
|
31-1/2" x 23-1/2" x 39-3/8"
(800 x 600 x 1000 mm)
|
39-3/8" x 28-3/4" x 39-3/8"
(1000 x 700 x 1000 mm)
|
|
Packing size
(L x W x H)
|
905 x 650 x 100 mm |
1040 x 765 x 900 mm |
|
N.W./G.W./CUFT. |
84kgs / 95kgs / 19' |
100kgs / 114kgs / 25' |
FEATURES:
► These tables are popular with small to medium size shops that use these
to allow each sander operation.
► The downdraft table provides a higher level of safety and convenience
by collecting dust at the source.
► Special design for heavy and finish sanding, routing and chop saw
applications.
► These units work to collect dust that otherwise would go into the air.
► Industrial strength steel cabinet with there foldable dust curtains help to
preventing the tiny dust from the operating polishing.
► Steel top with rubber grommets to hold and protect working piece.
► Low noise.
► Shop vacuum or dust collector easily cleans the metal tray that is full of
dust, with two outlets.
► Industrial toggle and NVR switch is positioned in front for operator
convenience.
|
